Material	Western Red Cedar
Profile	Shiplap
Width	145mm
Thickness	18mm
Face Coverage	125mm
Grade	No2 Clear & Better
Treatment	Untreated, Western Red Cedar is naturally rot resistant. While untreated Western Red Cedar is naturally resistant to rot, we highly recommend using OSMO stain to preserve its colour and protect against weathering, cracking, and expansion. Staining enhances the cedar’s durability, ensuring it maintains its appearance and integrity over time.
Finish	Planed Timber
Length	Available in 1.8m, 2.4m, 3.0m, 3.6m, and 4.8m
Buying Guide	Unsure which cladding to go for? Take a read of our full Cladding Buying Guide
Type	Softwood
Origin	Canada/North America
Durability	Class 2
Movement Class	Small
Knots	Very Few
Colour	Rich reddish-brown tones that weather gracefully to a silvery-grey patina
Modified Timber	No, Naturally Durable
Fixings	Stainless Steel
Recommended Wastage	10-15%
Key Points	Naturally durable with excellent resistance to rot and insects. Low density, making it thermally efficient and easy to work with. Lightweight yet strong, ideal for vertical or horizontal cladding. Stable under weather exposure, with minimal shrinkage.
Get a Quote!	Click Here



Naturally resistant to rot, decay, and insects, Western Red Cedar is low-maintenance and ages beautifully, especially when treated with a protective OSMO stain to maintain its rich colour and prevent weathering. With minimal knots and a smooth finish, this cedar profile provides a clean, uniform appearance that complements both contemporary and traditional spaces. Sustainably harvested and easy to install, Western Red Cedar Shadow Gap is perfect for those seeking a high-quality, eco-friendly timber solution.

Board Run

It's important to tell us which way your cladding will be running as depending on the desired orientation of your cladding, the timber needs to be cut differently.

Vertical run cladding naturally channels water downwards, however if cut incorrectly horizontal profile boards may trap water inside the shadow gaps, making it more susceptible to weather-related issues like rot. To combat this, horizontal boards are cut with a slight angle in the gaps to help the water run off, while vertical boards retain a nice crisp edge.

Other Options

• British Cedar Cladding - Environmentally friendly Cedar, grown sourced and machined in the UK
• Western Red Cedar 6" x 1" Planed Board - Profiled Version of the cladding
• Western Red Cedar Loglap - Profiled Version of the cladding
• Western Red Cedar T&G 144x19mm - Profiled Version of the cladding
• All Shadow Gap Cladding - Shop the range
